SPESIFICATION
| General | IC-F52D | IC-F62D | |
| Frequency coverage* (* Depending on version) |
136–174 MHz | (NXDN Version) 350–400, 400–470, 450–512, 450–520 MHz(dPMR Version) 400–470 MHz |
|
| Number of channels | 512 channels /128 zones | ||
| Type of emission* (* Depending on version) |
(NXDN Version) 16K0F3E*, 14K0F3E, 11K0F3E, 8K50F3E, 8K30F1E/D, 4K00F1E/D(dPMR Version) 16K0F3E*, 14K0F3E, 8K50F3E, 4K00F1E/D* 25 kHz bandwidth is no longer available for FCC Part 90 licensees for USA versions. |
||
| Power supply requirement | 7.5 V DC nominal | ||
| Current drain (approx.) | Tx | 1.8 A | |
| Rx | 500 mA /170 mA (Max. audio (internal SP)/Standby) |
||
| Antenna impedance | 50 Ω | ||
| Operating temperature range | −30 °C to +60 °C; −22 °F to +140 °F (Radio specifications) |
||
| Dimensions (W × H × D; Projections not included) |
56 × 91.5 × 36.5 mm; 2.2 × 3.6 × 1.4 in (With BP-294) |
||
| Weight (approx.) | 125 g; 4.4 oz (main unit) | ||
| 270 g; 9.5 oz (BP-294, MBB-3) | |||
| Transmitter | IC-F52D | IC-F62D |
| Output power (Hi, L2, L1) | 5 W, 2 W, 1 W | |
| Frequency stability | ±1.0 ppm | |
| Spurious emissions | 80 dB typ. (USA) | |
| 0.25 μW (≤ 1 GHz), 1.0 μW (> 1 GHz) (EUR) | ||
| FM Hum and noise | 57 dB typ. (@25 kHz), 55 dB typ. (@12.5 kHz) (USA) |
57 dB typ. (@25 kHz), 56 dB typ. (@12.5 kHz) (USA) |
| Audio harmonic distortion | 0.4% typ. (AF 1 kHz 40% deviation) | |
| FSK error | 1% typ. (@DVN, DN) | |
| Receiver | IC-F52D | IC-F62D | |
| Sensitivity | Analog (12 dB SINAD) |
0.23 μV typ. | |
| Analog (20 dB SINAD) |
−4.0 dBμV emf typ. (@25 kHz), −1.4 dBμV emf typ. (@12.5 kHz) |
−4.0 dBμV emf typ. (@25 kHz), −1.1 dBμV emf typ. (@12.5 kHz) |
|
| Digital (1% BER) |
−5.0 dBμV emf typ. (0.28 μV typ. ) (@DVN), −3.0 dBμV emf typ. (0.35 μV typ. ) (@DN) |
−4.0 dBμV emf typ. (0.32 μV typ. ) (@DVN), −3.0 dBμV emf typ. (0.35 μV typ. ) (@DN) |
|
| Adjacent channel |
Analog | 79 dB typ. (@25/20 kHz), 77 dB typ. (@12.5 kHz) |
76 dB typ. (@25/20 kHz), 73 dB typ. (@12.5 kHz) |
| Digital | 70 dB typ. (@DVN), 72 dB typ. (@DN) |
66 dB typ. (@DVN), 68 dB typ. (@DN) |
|
| Spurious response rejection | 76 dB typ. | 78 dB typ. | |
| Intermodulation rejection | Analog | 76 dB typ. (USA) 68 dB typ. (EUR) |
74 dB typ. (USA) 68 dB typ. (EUR) |
| Digital | 73 dBμV emf typ. (@DVN)/−40 dBm typ. (@DN) | ||
| Audio output power | Internal SP | 1300 mW typ. (at 5% distortion, 8 Ω load) | |
| External SP | 1000 mW typ. (at 5% distortion, 8 Ω load) 1300 mW typ. (at 5% distortion, 8 Ω load) with HM-222H* |
||
